Product Performance of Small Lab Three-layer Co-extruded Blown Film Machine:
* The single screw extruder is driven by international brand servo motor and extruded steadily.
* Select the international famous brand melt pressure and temperature sensor, and test data with high accuracy.
* SIEMENS touching screen PLC control system,friendly operation interface, easy to operate and powerful.
* Real-time measurement and graphic display of important data, such as extrusion system and auxiliary engine system, are convenient for observation.
* Emergency stop device and other safety devices to ensure the safety of the operator.
* SIEMENS touching screen PLC control system,highly intelligent, easy to operate.
* The film frame is operated electrically, and the operation is convenient.
* With CE certificate.
Application Scope of Small Lab Three-layer Co-extruded Blown Film Machine:
* Performance test of film blowing
* Master batch color dispersion test
* Optimization of blown film production technology
* Research on the dispersibility of pigments
* Study on film blowing properties of materials
* Defect detection and evaluation of fish eye, crystal point and so on
Technical Parameters / Technical parameters of small lab three-layer co-extruded blown film：
Model / HTBS-20C
Screw Diameter / 20mm
L/D Ratio / 28
Max. Speed / 120rpm
Heating/Cooling Method / Electrical heating / Air cooling
Max. Temp. / 350℃
Temp. Control Accuracy / ±1.0℃
Pressure Measuring Range / 0~50MPa
Pressure Measuring Accuracy / 0.2%F.S
Traction Speed / 0~10m/min Stepless Adjustment
Max. Width of Film Entrance / 200mm
Weight / 1280kg
Dimension / L×W×H 2980×1944×1670mm
